Royal Floors 5 mm glue-down vinyl plank with a 0.7 mm wear layer and anti-stain ultra-matte finish, in 1524 mm boards 228 mm or 182 mm wide. Ten colours, 25 year residential warranty.
Royal 5mm Vinyl Plank is a glue-down vinyl floor: each plank is fixed to the subfloor with a full trowel of adhesive, for a solid, quiet floor with no floating feel. It is PVC vinyl reinforced with a fibreglass mesh, under a heavy 0.7 mm wear layer and a UV-cured lacquer with an anti-stain coat.
The oak designs come in 1524 x 228 mm boards and the Australian timber designs in narrower 1524 x 182 mm boards, with a matte, lightly embossed surface and micro bevel. Each design has 12 to 15 unique planks and 72 to 90 unique prints, roughly triple the usual for vinyl, so the floor looks less repetitive.
It is backed by our 25 year residential warranty.
| Range | Royal 5mm Vinyl Plank |
| Brand | Royal Floors |
| Format | Glue-down vinyl plank |
| Board size | Oak designs 1524 x 228 mm; Australian timber designs 1524 x 182 mm |
| Thickness | 5 mm |
| Wear layer | 0.7 mm, UV-cured lacquer with anti-stain coat |
| Core | PVC vinyl with fibreglass mesh |
| Surface | Matte, light emboss |
| Edge | Micro bevel |
| Installation | Full trowel glue-down (high-temperature adhesive for sunny areas) |
| Acoustic rating | AAAC 4 star direct on concrete (L'nT,w 50); AAAC 6 star over 3 mm or 5 mm EverQuiet rubber underlay (L'nT,w 39), indicative and site specific |
| Underfloor heating | Hydronic in-slab only: surface up to 27°C, max 60 W/m² |
| Box coverage | Oak 2.084 m² (6 planks, 20.1 kg); Australian timber 1.664 m² (6 planks, 16.1 kg) |
| Plank variety | 12 to 15 unique planks, 72 to 90 unique prints |
| Warranty | 25 year residential; commercial by application (conditions apply) |
Every installation starts with a free measure at your home. We check the subfloor, test concrete and timber subfloors for moisture free of charge, and send your written quote within two working days of the measure. Our installation team then lays your new floor.
The manufacturer's installation guide for Royal 5mm Vinyl Plank sets out the subfloor, expansion gap and laying requirements.
Book a free measure and quote, or if you are laying it yourself, read our advice for DIY installers.
Follow the care and maintenance guide for Royal 5mm Vinyl Plank to keep your floor looking its best and to protect the warranty.
For general tips, read our floor care guide.
Product: 25 year residential; commercial by application (conditions apply), from the manufacturer.
Installation: our 2 year installation warranty covers the installation work we do.
See our warranty page for more about warranties.
It has our 25 year residential warranty. Commercial use is warranted by application (conditions apply). Our installation work is also covered by our 2 year installation warranty.
Glue-down vinyl is fixed to the subfloor with adhesive, so it feels solid, sounds quiet underfoot and does not move. Click floors such as our hybrids float over an underlay and go down faster, with an expansion gap around the edges.
Glued directly to concrete it tested at AAAC 4 star (L'nT,w 50). Over a 3 mm or 5 mm EverQuiet rubber underlay it reached AAAC 6 star (L'nT,w 39). Results depend on the building, so check your strata by-laws.
No. Vinyl planks in wet areas do not meet the National Construction Code, so we do not install them there.
Yes. Visit our Penrith, Campbelltown, Hornsby or Logan showroom, or book a free measure and quote and we will bring samples to your home.
